Case CX30C Mini Excavator

Mini Excavator
Mini Excavator
Mini Excavator
Mini Excavator
Mini Excavator
Mini Excavator
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

13.72ft in

C

Shipping Height of Unit

8.21ft in

I

Max Cutting Height

14.01ft in

J

Max Loading Height

9.62ft in

K

Max Reach Along Ground

14.82ft in

L

Max Vertical Wall Digging Depth

6.85ft in

M

Max Digging Depth

8.21ft in

Dimensions

B

Width to Outside of Tracks

5.09ft in

D

Length of Track on Ground

4.89ft in

E

Ground Clearance

0.96ft in

G

Height to Top of Cab

8.21ft in

H

Tail Swing Radius

2.47ft in


Specifications

Engine

Fuel

Diesel

Fuel injection

Mechanical

Emissions level

Tier 4 Final

Number of Cylinders

3

Max speed

2.7mph

Engine Model

Kubota D1305

Gross Power

24.8hp

Cooling system

Water-cooled

Net Power

23.2hp

Power Measured @

2300rpm

Displacement

77cu in

Max Torque

60.1lb ft

Torque Measured @

1600rpm

Drive Train

Maximum traction force

4800lb

Gradeability

30degrees

Ground pressure

4.1psi

Capacities

Engine oil w/ filter change

1.6gal

Fuel Tank

8gal

Hydraulic Tank

14.6gal

Radiator

1.4gal

Operational

Operating Weight

6636lb

Electrical

Alternator

40 amp

Voltage

12V

Battery

1 x 12 V x 80 Ah

Swing Mechanism

Swing Speed

9.1rpm

Undercarriage

Number of Track Rollers per Side

4

Hydraulic System

Main pump - Maximum flow

14.6gal/min

Relief pressure

3130 psi, 220 bar

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

3 ft 8 in (1.12 m) Arm

Shipping Height of Unit

8.3ft in

Shipping Length of Unit

13.8ft in

Max Digging Depth

8.3ft in

Max Reach Along Ground

14.9ft in

Max Cutting Height

14.1ft in

Max Loading Height

9.7ft in

Max Vertical Wall Digging Depth

6.9ft in

Dimensions

Width to Outside of Tracks

5.1ft in

Height to Top of Cab

8.3ft in

Ground Clearance

1ft in

Tail Swing Radius

2.5ft in

Length of Track on Ground

4.9ft in
