Case CX300D Hydraulic Excavator

Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Units

Dimensions

Boom/Stick Option (HEX) 1

L

Max Vertical Wall Digging Depth

20.02ft in

M

Max Digging Depth

23.3ft in

Boom/Stick Option (HEX) 2

L

Max Vertical Wall Digging Depth

18.87ft in

M

Max Digging Depth

21.56ft in

Boom/Stick Option (HEX) 3

M

Max Digging Depth

24.87ft in

Dimensions

E

Ground Clearance

1.51ft in

H

Tail Swing Radius

10.37ft in


Specifications

Engine

Fuel injection

Direct injection – electronic

Emission Tier Level

Tier 4

Fuel Filter

Replaceable, full flow spin-on cartridge

Air filter type

Dry type element w/ warning restriction indicator

Number of Cylinders

6

Engine Model

Isuzu 6 HK1X

Net Power

154hp

Power Measured @

1800rpm

Max Torque

626.2lb ft

Displacement

476cu in

Fuel Type

Requires ultra low-sulfur fuel B5 biodiesel tolerant

Bore

4.6in

Stroke

5in

Oil Filter

Replaceable, full flow spin-on cartridge

Capacities

Engine oil w/ filter change

10.9gal

Swing drive

0.4gal

Fuel Tank

120.8gal

Hydraulic Tank

38.9gal

Cooling system

9.5gal

DEF Tank

31.8gal

Final Drive

2.6gal

Hydraulic system

79.3gal

Operational

Arm Breakout Force

31473.3lb

Operating Weight

66478.2lb

Arm size

10433.1ft in

Performance

Lift over end 10\' radius - lbs (kg)

19378.7lb

Lift over end Max. reach

9347.6lb

Lift over side 10\' radius

19378.7lb

Lift over side Max. reach

7032.8lb

Transmission

Max Speed

3.4mph

Swing Mechanism

Swing Speed

10rpm

Undercarriage

Track Shoe Width

31.5in

Hydraulic System

Main pump - Maximum flow

128.4gal/min

System relief pressure

49.8psi

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

10ft,5in,Arm_(3.18m)

Mximum dig radius

420.1in

Dig radius at ground line

413in

Dump height

278.8in

Bucket rotation

176degrees

Minimum swing radius

158.7in

Max Digging Depth

23.3ft in

Max Vertical Wall Digging Depth

20.1ft in

Max.Dumping Height

23.3ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

8ft,8in,Arm_(2.65m)

Maximum dig radius

402.4in

Dig radius at ground line

394.9in

Dump height

272.9in

Maximum reach height

391in

Bucket rotation

176degrees

Minimum swing radius

156.7in

Max Digging Depth

21.6ft in

Max Vertical Wall Digging Depth

18.9ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

8ft,8in,Arm_(3.66m)

Maximum dig radius

439.4in

Dig radius at ground line

432.3in

Dump height

291in

Maximum reach height

409.1in

Bucket rotation

176degrees

Minimum swing radius

160.7in

Max Digging Depth

24.9ft in

Brakes

Brakes Type

Dual stage relief or counter balance design

Service brake

Mechanical disc

Travel control

SAHR disc – each motor

Dimensions

Boom length

0.1ft in

Ground pressure

6.4psi

Ground Clearance

1.6ft in

Tail Swing Radius

10.4ft in
