Case CX210 Long Reach Hydraulic Excavator

Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

41.18ft in

C

Shipping Height of Unit

9.85ft in

I

Max Cutting Height

42.56ft in

J

Max Loading Height

35.21ft in

K

Max Reach Along Ground

50.83ft in

L

Max Vertical Wall Digging Depth

33.7ft in

M

Max Digging Depth

39.38ft in

Dimensions

B

Width to Outside of Tracks

10.5ft in

D

Length of Track on Ground

12.01ft in

E

Ground Clearance

1.51ft in

G

Height to Top of Cab

9.72ft in

H

Tail Swing Radius

9.26ft in

Undercarriage

N

Shoe Size

31.5in


Specifications

Engine

Number of Cylinders

6

Engine Make

2239

Engine Model

6TAA-5904

Gross Power

153hp

Net Power

147hp

Power Measured @

1950rpm

Displacement

359cu in

Max Torque

450lb ft

Torque Measured @

1400rpm

Aspiration

Turbocharged

Operational

Operating Weight

47584lb

Fuel Capacity

90gal

Cooling System Fluid Capacity

7.2gal

Hydraulic System Fluid Capacity

54.5gal

Engine Oil Capacity

6.4gal

Swing Drive Fluid Capacity

1.3gal

Operating Voltage

24V

Alternator Supplied Amperage

45amps

Hydraulic System Relief Valve Pressure

4975psi

Hydraulic Pump Flow Capacity

53.1gal/min

Swing Mechanism

Swing Speed

11.9rpm

Undercarriage

Number of Shoes per Side

49

Shoe Size

31.5in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

8

Ground Pressure

4.9psi

Max Travel Speed

3.4mph

Drawbar Pull

41140lb

Buckets

Reference Bucket Capacity

0.7yd3

Minimum Bucket Capacity

0.5yd3

Maximum Bucket Capacity

0.7yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 28'7" (8700mm)/ Stick 21'0" (6400mm)

Shipping Height of Unit

9.9ft in

Shipping Length of Unit

41.2ft in

Max Digging Depth

39.4ft in

Max Reach Along Ground

50.9ft in

Max Cutting Height

42.6ft in

Max Loading Height

35.3ft in

Max Vertical Wall Digging Depth

33.7ft in

Dimensions

Width to Outside of Tracks

10.5ft in

Height to Top of Cab

9.8ft in

Ground Clearance

1.6ft in

Removal Counterweight Clearance

3.5ft in

Tail Swing Radius

9.3ft in

Length of Track on Ground

12.1ft in
