Case CX20B Mini Excavator

Case CX20B Mini Excavator Specs front
Case CX20B Mini Excavator Specs front
Case CX20B Mini Excavator Specs side
Case CX20B Mini Excavator Specs side
Case CX20B Mini Excavator Specs extended
Case CX20B Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

13 ft in

J

Max Loading Height

8.93 ft in

K

Max Reach Along Ground

13.75 ft in

L

Max Vertical Wall Digging Depth

5.88 ft in

M

Max Digging Depth

7.55 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

13.75 ft in

J

Max Loading Height

9.68 ft in

K

Max Reach Along Ground

14.83 ft in

L

Max Vertical Wall Digging Depth

6.99 ft in

M

Max Digging Depth

8.7 ft in

Dimensions

B

Width to Outside of Tracks

4.6 ft in

D

Length of Track on Ground

4.89 ft in

E

Ground Clearance

1.58 ft in

G

Height to Top of Cab

8.08 ft in

H

Tail Swing Radius

2.3 ft in

Undercarriage

F

Track Gauge

3.78 ft in

N

Shoe Size

9.85 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2348

Engine Model

3TNV82A-SYB

Net Power

23 hp

Power Measured @

2200 rpm

Displacement

81.2 cu in

Max Torque

59.1 lb ft

Torque Measured @

1320 rpm

Operational

Operating Weight

4629.8 lb

Fuel Capacity

7.4 gal

Cooling System Fluid Capacity

1.1 gal

Hydraulic System Fluid Capacity

6.7 gal

Engine Oil Capacity

1.5 gal

Hydraulic Pump Flow Capacity

6.9 gal/min

Undercarriage

Shoe Size

9.9 in

Max Travel Speed

2.6 mph

Track Gauge

3.8 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Std. Dipper 0.98M

Max Digging Depth

7.6 ft in

Max Reach Along Ground

13.8 ft in

Max Cutting Height

13 ft in

Max Loading Height

9 ft in

Max Vertical Wall Digging Depth

5.9 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Long Dipper 1.33M

Max Digging Depth

8.7 ft in

Max Reach Along Ground

14.9 ft in

Max Cutting Height

13.8 ft in

Max Loading Height

9.7 ft in

Max Vertical Wall Digging Depth

7 ft in

Dimensions

Width to Outside of Tracks

4.6 ft in

Height to Top of Cab

8.1 ft in

Ground Clearance

1.6 ft in

Removal Counterweight Clearance

1.6 ft in

Tail Swing Radius

2.3 ft in

Length of Track on Ground

4.9 ft in
