Case CX130B LC Hydraulic Excavator

Case CX130B LC Hydraulic Excavator Specs front
Case CX130B LC Hydraulic Excavator Specs front
Case CX130B LC Hydraulic Excavator Specs side
Case CX130B LC Hydraulic Excavator Specs side
Case CX130B LC Hydraulic Excavator Specs extended
Case CX130B LC Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

25.07 ft in

C

Shipping Height of Unit

9.26 ft in

I

Max Cutting Height

29.7 ft in

J

Max Loading Height

21.92 ft in

K

Max Reach Along Ground

28.35 ft in

L

Max Vertical Wall Digging Depth

17.56 ft in

M

Max Digging Depth

19.85 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

25 ft in

C

Shipping Height of Unit

9.26 ft in

I

Max Cutting Height

28.78 ft in

J

Max Loading Height

20.97 ft in

K

Max Reach Along Ground

26.81 ft in

L

Max Vertical Wall Digging Depth

16.28 ft in

M

Max Digging Depth

18.18 ft in

Boom/Stick Option (HEX) 3

A

Shipping Length of Unit

- -

C

Shipping Height of Unit

- -

I

Max Cutting Height

- -

J

Max Loading Height

- -

K

Max Reach Along Ground

- -

L

Max Vertical Wall Digging Depth

- -

M

Max Digging Depth

- -

Dimensions

B

Width to Outside of Tracks

8.5 ft in

D

Length of Track on Ground

9.98 ft in

E

Ground Clearance

1.42 ft in

G

Height to Top of Cab

9.16 ft in

H

Tail Swing Radius

6.99 ft in

Undercarriage

F

Track Gauge

6.53 ft in

N

Shoe Size

23.63 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2353

Engine Model

4JJ1X, Tier III certified

Net Power

95.3 hp

Power Measured @

2000 rpm

Displacement

183 cu in

Max Torque

265 lb ft

Torque Measured @

1600 rpm

Aspiration

Turbocharged and aftercooled

Operational

Operating Weight

28400 lb

Fuel Capacity

68.7 gal

Cooling System Fluid Capacity

4 gal

Hydraulic System Fluid Capacity

41.5 gal

Engine Oil Capacity

4.5 gal

Swing Drive Fluid Capacity

0.6 gal

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Hydraulic System Relief Valve Pressure

4975 psi

Hydraulic Pump Flow Capacity

68.2 gal/min

Swing Mechanism

Swing Speed

14.3 rpm

Undercarriage

Number of Shoes per Side

46

Shoe Size

23.7 in

Number of Carrier Rollers per Side

1

Number of Track Rollers per Side

7

Ground Pressure

7.5 psi

Max Travel Speed

3.5 mph

Drawbar Pull

25853 lb

Track Gauge

6.6 ft in

Buckets

Minimum Bucket Capacity

0.5 yd3

Maximum Bucket Capacity

1 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 4630mm / Stick 9\'11\" 3010mm

Shipping Height of Unit

9.3 ft in

Shipping Length of Unit

25.1 ft in

Max Digging Depth

19.9 ft in

Max Reach Along Ground

28.4 ft in

Max Cutting Height

29.7 ft in

Max Loading Height

22 ft in

Max Vertical Wall Digging Depth

17.6 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 4630mm / Stick 8\'2\" 2500mm

Shipping Height of Unit

9.3 ft in

Shipping Length of Unit

25 ft in

Max Digging Depth

18.2 ft in

Max Reach Along Ground

26.9 ft in

Max Cutting Height

28.8 ft in

Max Loading Height

21 ft in

Max Vertical Wall Digging Depth

16.3 ft in

Dimensions

Width to Outside of Tracks

8.5 ft in

Height to Top of Cab

9.2 ft in

Ground Clearance

1.5 ft in

Removal Counterweight Clearance

3 ft in

Tail Swing Radius

7 ft in

Length of Track on Ground

10 ft in
