Case CX130 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
25ft in
C
Shipping Height Of Unit
9.09ft in
I
Max Cutting Height
31ft in
J
Max Loading Height
23.17ft in
K
Max Reach Along Ground
28.25ft in
L
Max Vertical Wall Digging Depth
17.5ft in
M
Max Digging Depth
20ft in
Boom/Stick Option (Hex) 1
Boom 15'2" (4630mm)/ Stick 10' (3050 mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
24.83ft in
I
Max Cutting Height
30.08ft in
C
Shipping Height Of Unit
8.99ft in
J
Max Loading Height
22.25ft in
K
Max Reach Along Ground
26.67ft in
L
Max Vertical Wall Digging Depth
16.25ft in
M
Max Digging Depth
18.18ft in
Boom/Stick Option (Hex) 2
Boom 15'2" (4630mm)/ Stick 8'2" (2500 mm)
Dimensions
E
Ground Clearance
1.42ft in
G
Height To Top Of Cab
9ft in
B
Width To Outside Of Tracks
8.5ft in
D
Length Of Track On Ground
9.17ft in
H
Tail Swing Radius
6.92ft in
Removal Counterweight Clearance
2.92ft in
Undercarriage
F
Track Gauge
6.53ft in
N
Shoe Size
23.63in
Number Of Shoes Per Side
43
Drawbar Pull
22481lb
Number Of Track Rollers Per Side
7
Number Of Carrier Rollers Per Side
1
Max Travel Speed
3.5mph
Ground Pressure
4.8psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2239
Engine Model
4TA-390, Tier II certified
Gross Power
110hp
Net Power
106hp
Power Measured @
2200rpm
Max Torque
325lb ft
Displacement
239cu in
Aspiration
turbocharged and aftercooled
Torque Measured @
1450rpm
Operational
Operating Weight
27057lb
Fuel Capacity
66gal
Cooling System Fluid Capacity
4.7gal
Hydraulic System Fluid Capacity
32gal
Operating Voltage
24V
Engine Oil Capacity
2.5gal
Swing Drive Fluid Capacity
0.6gal
Alternator Supplied Amperage
45amps
Hydraulic System Relief Valve Pressure
4975psi
Hydraulic Pump Flow Capacity
67.1gal/min
Swing Mechanism
Swing Speed
13.8rpm
Buckets
Reference Bucket Capacity
0.6yd3
Minimum Bucket Capacity
0.3yd3
Maximum Bucket Capacity
1.1yd3
