Case AP600 Asphalt Paver

Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Units

Dimensions

Dimensions

A

Length w/ Screed

21ft in

B

Transport Width

8.21ft in

C

Transport Height

12.14ft in


Specifications

Fuel Tank

Fuel Tank Capacity

68.7gal

Engine

Engine Model

3056E ATAAC

Gross Power

173hp

Net Power

162hp

Displacement

366cu in

Bore

4in

Stroke

5in

Engine Model

Cat 3056E

Flywheel Power

173hp

Net Power - EEC 80/1269

162hp

Operational

Operating Weight w/ Screed

39903.7lb

Operating Voltage

24V

Alternator Supplied Amperage

55amps

Hopper/Paver

Paving Width - std

8.3ft in

Paving Width - max

15.5ft in

Travel Speed - max

9.4mph

Weights

Tractor Weight

31195lb

Operating Weight

39242lb

Dimensions

Length w/ Screed

21ft in

Width w/ Hopper Open

6ft in

Transport Width

8.3ft in

Transport Height

12.2ft in

Track Width

126in

Wheel Base

7.6ft in

Operating Specifications

Maximum Speed

196.9mph

Hopper Capacity

195 ft/Sh Ton

Paving Width Minimum

8.2ft in

Paving Width

25.6ft in
