Case 9010B Hydraulic Excavator

Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

25.04ft in

C

Shipping Height of Unit

9.09ft in

I

Max Cutting Height

30.88ft in

J

Max Loading Height

23.04ft in

K

Max Reach Along Ground

28.42ft in

L

Max Vertical Wall Digging Depth

17.85ft in

M

Max Digging Depth

19.85ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

24.94ft in

C

Shipping Height of Unit

9.09ft in

I

Max Cutting Height

29.83ft in

J

Max Loading Height

21.99ft in

K

Max Reach Along Ground

26.91ft in

L

Max Vertical Wall Digging Depth

16.34ft in

M

Max Digging Depth

18.21ft in

Dimensions

B

Width to Outside of Tracks

8.5ft in

D

Length of Track on Ground

9.13ft in

E

Ground Clearance

1.45ft in

G

Height to Top of Cab

9.09ft in

H

Tail Swing Radius

6.73ft in

Undercarriage

N

Shoe Size

23.6in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

4TA-390

Net Power

106hp

Power Measured @

2200rpm

Displacement

239cu in

Max Torque

290lb ft

Torque Measured @

1600rpm

Aspiration

Turbocharged and Aftercooled

Operational

Operating Weight

28000lb

Fuel Capacity

63.4gal

Cooling System Fluid Capacity

4.2gal

Hydraulic System Fluid Capacity

32.8gal

Engine Oil Capacity

2.8gal

Swing Drive Fluid Capacity

0.6gal

Operating Voltage

24V

Alternator Supplied Amperage

45amps

Hydraulic System Relief Valve Pressure

4550psi

Hydraulic Pump Flow Capacity

32gal/min

Swing Mechanism

Swing Speed

13.4rpm

Undercarriage

Number of Shoes per Side

44

Shoe Size

23.6in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

6

Ground Pressure

4.9psi

Max Travel Speed

3.4mph

Drawbar Pull

22260lb

Buckets

Reference Bucket Capacity

0.7yd3

Minimum Bucket Capacity

0.5yd3

Maximum Bucket Capacity

1yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 15'5" (4700mm)/ Stick 9'10" (3000mm)

Shipping Height of Unit

9.1ft in

Shipping Length of Unit

25.1ft in

Max Digging Depth

19.9ft in

Max Reach Along Ground

28.5ft in

Max Cutting Height

30.9ft in

Max Loading Height

23.1ft in

Max Vertical Wall Digging Depth

17.9ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 15'5" (4700mm)/ Stick 8'2" (2500mm)

Shipping Height of Unit

9.1ft in

Shipping Length of Unit

25ft in

Max Digging Depth

18.3ft in

Max Reach Along Ground

27ft in

Max Cutting Height

29.9ft in

Max Loading Height

22ft in

Max Vertical Wall Digging Depth

16.4ft in

Dimensions

Width to Outside of Tracks

8.5ft in

Height to Top of Cab

9.1ft in

Ground Clearance

1.5ft in

Removal Counterweight Clearance

3ft in

Tail Swing Radius

6.8ft in

Length of Track on Ground

9.2ft in
