Case 850L XLT Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length w/ Blade

14.47 ft in

B

Width Over Tracks

6.67 ft in

C

Height to Top of Cab

9.1 ft in

D

Length of Track on Ground

7.71 ft in

E

Ground Clearance

1.25 ft in

Undercarriage

G

Track Gauge

5.16 ft in

H

Standard Shoe Size

20 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2239

Engine Model

Family IV 667TA/E66 Tier III

Gross Power

99.3 hp

Net Power

96.6 hp

Power Measured @

2000 rpm

Max Torque

321 lb ft

Displacement

408.9 cu in

Torque Measured @

1400 rpm

Operational

Operating Weight

19621.2 lb

Fuel Capacity

50.1 gal

Cooling System Fluid Capacity

7.1 gal

Engine Oil Capacity

4 gal

Hydraulic Fluid Capacity

20 gal

Final Drives Fluid Capacity

3.8 gal

Operating Voltage

12 V

Alternator Supplied Amperage

90 amps

Transmission

Transmission Type

Hydrostatic

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

6.1 mph

Max Speed - Reverse

6.1 mph

Undercarriage

Ground Pressure

5.9 psi

Ground Contact Area

3689.1 in2

Standard Shoe Size

20 in

Number of Shoes per Side

40

Number of Track Rollers per Side

7

Number of Carrier Rollers per Side

1

Track Pitch

6.8 in

Track Gauge

5.2 ft in

Hydraulic System

Relief Valve Pressure

3000 psi

Pump Flow Capacity

20.3 gal/min

Standard Blade

Width

8.7 ft in

Height

36 in

Capacity

2.2 yd3

Blade Angle (both directions)

25 degrees

Cutting Depth

19.1 in

Dimensions

Length w/ Blade

14.5 ft in

Width Over Tracks

6.7 ft in

Height to Top of Cab

9.1 ft in

Length of Track on Ground

7.8 ft in

Ground Clearance

1.3 ft in
