Case 686G XR Telescopic Forklift

Telescopic Forklift
Telescopic Forklift
Telescopic Forklift
Telescopic Forklift
Telescopic Forklift
Telescopic Forklift
Units

Dimensions

Dimensions

A

Length to Fork Face

20.35ft in

B

Width Over Tires

8.54ft in

C

Overall Height

7.88ft in

D

Wheelbase

9.85ft in

E

Ground Clearance

15.99ft in

Lift

F

Max Lift Height

42ft in

G

Max Forward Reach

27.89ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

4T-390

Gross Power

110hp

Net Power

99hp

Power Measured @

2500rpm

Max Torque

293lb ft

Torque Measured @

1500rpm

Displacement

239cu in

Aspiration

Turbocharged

Operational

Operating Weight

19600lb

Fuel Capacity

35gal

Hydraulic System Fluid Capacity

40gal

Operating Voltage

12V

Alternator Supplied Amperage

62amps

Tire Size

13.00x24 12PR L2/G2

Transmission

Transmission Type

Powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - forward

21mph

Max Speed - reverse

21mph

Hydraulic

Pump Type

axial piston

Pump Flow Capacity

34gal/min

Lift

Max Lift Capacity

6700lb

Max Lift Height

42ft in

Max Load at Max Height

6000lb

Max Forward Reach

27.9ft in

Max Load at Max Reach

1000lb

Dimensions

Length to Fork Face

20.4ft in

Width Over Tires

8.6ft in

Overall Height

7.9ft in

Wheelbase

9.9ft in

Ground Clearance

16ft in

Turning Radius Outside Tires

12ft in
