Case 650K LT Crawler Loader

Crawler Loader
Crawler Loader
Crawler Loader
Crawler Loader
Crawler Loader
Crawler Loader
Units

Dimensions

Dimensions

A

Length with Bucket on Ground

16.74ft in

B

Width to Outside of Tracks

9.17ft in

C

Height to Top of Cab

9.1ft in

E

Ground Clearance

1.45ft in

G

Clearance at Full Height and Dump

9.1ft in

H

Reach at Dump Height

9.15ft in

F

Length to Front of Track

14.03ft in

Undercarriage

D

Length of Track on Ground

16ft in

I

Track Gauge

57in


Specifications

Engine

Engine Make

2239

Engine Model

family III 445T/M2 diesel Tier II certified

Net Power

74.8hp

Displacement

274cu in

Operational

Operating Weight

18200lb

Fuel Capacity

50gal

Cooling System Fluid Capacity

20gal

Engine Oil Capacity

14.4gal

Final Drive Fluid Capacity - each

15gal

Hydraulic System Fluid Capacity

20gal

Operating Voltage

12V

Alternator Supplied Amperage

65amps

Undercarriage

Track Shoe Width

16in

Number of Shoes per Side

38

Number of Track Rollers per Side

6

Length of Track on Ground

16ft in

Ground Contact Area

2810in2

Ground Pressure

6.5psi

Track Gauge

57in

Hydraulic

Pump Type

Deep sump plate cooler with pressurized under piston nozzle

Pump Flow Capacity

20.8gal/min

Relief Valve Pressure

20855psi

Dimensions

Length to Front of Track

14.1ft in

Length with Bucket on Ground

16.8ft in

Width to Outside of Tracks

9.2ft in

Height to Top of Cab

9.1ft in

Ground Clearance

1.5ft in

Clearance at Full Height and Dump

9.1ft in

Reach at Dump Height

9.2ft in
