Case 580B Loader Backhoe

Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Units

Dimensions

Backhoe

J

Load Height - Std

10.83ft in

K

Reach From Swivel - Std

17.52ft in

L

Dig Depth - Std

13.98ft in

Dimensions

A

Transport Length

21.66ft in

B

Transport Width

6.4ft in

C

Transport Height

7.65ft in

D

Wheelbase

6.53ft in

E

Ground Clearance

1.15ft in

Loader

G

Clearance at Max Dump Height

8.57ft in

H

Reach at Max Dump Height

2.04ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

J.I. Case

Engine Model

G188D

Net Power

43hp

Gross Power

50hp

Power Measured @

2100rpm

Torque Measured @

1900rpm

Net Max Torque

132lb ft

Bore

3.8in

Stroke

4.2in

Operational

Max Weight

11000lb

Fuel Capacity

22gal

Hydraulic System Fluid Capacity

11gal

Oil System Fluid Capacity

1.1gal

Cooling System Fluid Capacity

4.2gal

Tire Size Front - 2wd / 4wd

7.50x16

Rear Tires Size 2wd/4wd

14.9x24

Operating Voltage

12V

Transmission

Transmission Type

Synchronized shuttle

Number of Forward Gears

8

Number of Reverse Gears

8

Max Speed - Forward

20.8mph

Max Speed Reverse

22.8mph

Backhoe

Dig Depth - Std

14ft in

Dig Depth - Ext

18ft in

Reach From Swivel - Std

17.6ft in

Reach From Swivel - Ext

25.1ft in

Bucket Dig Force - Std

9400lb

Bucket Dig Force - Ext

9400lb

Load Height - Std

10.9ft in

Load Height - Ext

14.8ft in

Loader

Bucket Capacity

1yd3

Bucket Width

80in

Lift Capacity at Full Height

4000lb

Clearance at Max Dump Height

8.6ft in

Reach at Max Dump Height

2.1ft in

Hydraulic

Pump Flow Capacity

26gal/min

Relief Valve Pressure

2200psi

Dimensions

Rear Tread Range

76in

Front Wheel Tread Width

56.7in

Transport Length

21.7ft in

Transport Width

6.4ft in

Transport Height

7.7ft in

Height to Top of Suspended Cab

5.9ft in

Wheelbase

6.6ft in

Ground Clearance

1.2ft in
