Case 550H LGP Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length w/ Blade

13.03ft in

B

Width Over Tracks

7.52ft in

C

Height to Top of Cab

8.57ft in

D

Length of Track on Ground

6.5ft in

E

Ground Clearance

1.16ft in

Undercarriage

G

Track Gauge

5.35ft in

H

Standard Shoe Size

25.99in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

4T-390

Gross Power

80hp

Net Power

70hp

Power Measured @

2200rpm

Max Torque

220lb ft

Displacement

239cu in

Torque Measured @

1500rpm

Aspiration

Turbocharged

Operational

Operating Weight

14960lb

Fuel Capacity

30.5gal

Cooling System Fluid Capacity

4.2gal

Engine Oil Capacity

2.8gal

Hydraulic Fluid Capacity

10.4gal

Final Drives Fluid Capacity

1.6gal

Operating Voltage

12V

Alternator Supplied Amperage

65amps

Transmission

Transmission Type

Constant mesh modulated

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

5.8mph

Max Speed - Reverse

6.4mph

Undercarriage

Ground Pressure

3.7psi

Ground Contact Area

4056in2

Standard Shoe Size

26in

Number of Shoes per Side

37

Number of Track Rollers per Side

6

Number of Carrier Rollers per Side

1

Track Pitch

6.3in

Track Gauge

5.4ft in

Hydraulic System

Relief Valve Pressure

2500psi

Pump Flow Capacity

21.9gal/min

Standard Blade

Width

9.2ft in

Height

33in

Capacity

1.9yd3

Blade Angle (both directions)

25degrees

Cutting Depth

2.3in

Dimensions

Length w/ Blade

13.1ft in

Width Over Tracks

7.6ft in

Height to Top of Cab

8.6ft in

Length of Track on Ground

6.5ft in

Ground Clearance

1.2ft in
