Case 420CT Series 3 Multi Terrain Loader

Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Multi Terrain Loader
Units

Dimensions

Dimensions

B

Width Over Tracks

5.42ft in

C

Height to Top of Cab

6.63ft in

E

Ground Clearance

8.39in

G

Clearance at Max Lift and Dump

7.94ft in

H

Reach at Max Lift and Dump

2.07ft in

Undercarriage

D

Length of Track on Ground

4.72ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

432T/M3

Gross Power

74hp

Net Power

69hp

Power Measured @

2500rpm

Peak Torque

203lb ft

Torque Measured @

1400rpm

Displacement

195cu in

Aspiration

Turbocharged

Operational

Operating Weight

8340lb

Fuel Capacity

22gal

Cooling System Fluid Capacity

3.1gal

Engine Oil Capacity

2.3gal

Hydraulic System Fluid Capacity

13.2gal

Operating Voltage

12V

Alternator Supplied Amperage

95amps

Max Speed - low range

5.8mph

Max Speed - high range

8.4mph

Undercarriage

Ground Contact Area

1424in2

Ground Pressure

5.8psi

Number of Track Rollers per Side

3

Length of Track on Ground

4.8ft in

Width of Track

12.6in

Loader

Operating Load

2860lb

Tipping Angle

5715degrees

Bucket Capacity

0.6yd3

Hydraulic

Pump Type

Gear

Pump Flow

23.8gal/min

Dimensions

Width Over Tracks

5.5ft in

Length with Bucket

10.8ft in

Length with out Bucket

8.6ft in

Height to Top of Cab

6.7ft in

Ground Clearance

8.4in

Clearance at Max Lift and Dump

8ft in

Reach at Max Lift and Dump

2.1ft in

Turning Radius from Center - machine rear

57.1in

Turning Radius from Center - inc bucket

80.8in
