Case 420 Skid Steer Loader

Case 420 Skid Steer Loader Specs front
Case 420 Skid Steer Loader Specs front
Case 420 Skid Steer Loader Specs side
Case 420 Skid Steer Loader Specs side
Case 420 Skid Steer Loader Specs back
Case 420 Skid Steer Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket

10.27 ft in

B

Width Over Tires

4.11 ft in

C

Height to Top of Cab

6.3 ft in

D

Wheelbase

3.45 ft in

E

Ground Clearance

8 in

F

Length w/o Bucket

8.34 ft in

G

Clearance at Max Lift and Dump

7.45 ft in

H

Reach at Max Lift and Dump

23.6 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

422T/M2, Tier II certified

Gross Power

59 hp

Net Power

56 hp

Power Measured @

2900 rpm

Displacement

134 cu in

Aspiration

turbocharged

Operational

Operational Weight

5813 lb

Fuel Capacity

22 gal

Cooling System Fluid Capacity

4.5 gal

Engine Oil Fluid Capacity

2.8 gal

Hydraulic System Fluid Capacity

13.2 gal

Chain Box Fluid Capacity - each side

2 gal

Operating Speed

6.9 mph

Max Speed

6.5 mph

Tire Size

10.00 x 16.5

Operating Voltage

12 V

Alternator Supplied Amperage

55 amps

Loader

Operating Load Rating

1750 lb

Tipping Angle

3500 degrees

Bucket Capacity

0.5 yd3

Hydraulic

Pump Type

Gear

Pump Flow Capacity

19.5 gal/min

Relief Valve Pressure

3050 psi

Dimensions

Length with Bucket

10.3 ft in

Length w/o Bucket

8.4 ft in

Width Over Tires

4.2 ft in

Height to Top of Cab

6.3 ft in

Clearance at Max Lift and Dump

7.5 ft in

Wheelbase

3.5 ft in

Ground Clearance

8 in

Reach at Max Lift and Dump

23.6 in

Turning Radius from Center - machine rear

57.6 in

Turning Radius from Center - inc bucket

73.2 in
