Case 221E Wheel Loader

Case 221E Wheel Loader Specs front
Case 221E Wheel Loader Specs front
Case 221E Wheel Loader Specs side
Case 221E Wheel Loader Specs side
Case 221E Wheel Loader Specs back
Case 221E Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

8.53 ft in

Dimensions

A

Length with Bucket on Ground

18.49 ft in

B

Width Over Tires

6.25 ft in

C

Height to Top of Cab

9.17 ft in

D

Wheelbase

7.71 ft in

E

Ground Clearance

1.08 ft in

F

Hinge Pin - Max Height

11.11 ft in

H

Reach at Max Lift and Dump

2.85 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2349

Engine Model

F4M2011, Tier 2 certified

Net Power

59 hp

Gross Power

60 hp

Power Measured @

2500 rpm

Displacement

190 cu in

Torque Measured @

1700 rpm

Max Torque

131

Operational

Operating Weight

11947 lb

Fuel Capacity

26 gal

Hydraulic System Fluid Capacity

17.7 gal

Engine Oil Fluid Capacity

2.7 gal

Front Axle/Diff Fluid Capacity

2.1 gal

Rear Axle/Diff Fluid Capacity

2.1 gal

Static Tipping Weight

9358 lb

Turning Radius

13.5 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

55 amps

Rear Axle Oscillation

24 degrees

Tire Size

365/80 R20 EM SPT9

Transmission

Transmission Type

Hydrostatic transmission

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed - Forward

12.4 mph

Max Speed - Reverse

12.4 mph

Hydraulic System

Pump Type

Open-centered pressure/flow compensated

Relief Valve Setting

3626

Pump Flow Capacity

18.5 gal/min

Raise Time

6 sec

Dump Time

1 sec

Lower Time

3 sec

Bucket

Breakout Force

9723 lb

Dump Clearance at Max Raise

8.6 ft in

Bucket Width

6.9 ft in

Bucket Capacity - heaped

1.4 yd3

Bucket Capacity - struck

1.1 yd3

Dimensions

Length with Bucket on Ground

18.5 ft in

Width Over Tires

6.3 ft in

Height to Top of Cab

9.2 ft in

Ground Clearance

1.1 ft in

Wheelbase

7.8 ft in

Hinge Pin - Max Height

11.2 ft in

Reach at Max Lift and Dump

2.9 ft in
