Case 1450B Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length w/ Blade

15.92ft in

C

Height to Top of Cab

10.31ft in

E

Ground Clearance

1.25ft in

F

Length w/o Blade

12.34ft in

Undercarriage

G

Track Gauge

6.17ft in

H

Standard Shoe Size

24.02in


Specifications

Engine

Number of Cylinders

6

Engine Make

Case

Engine Model

A504BDT

Gross Power

152hp

Net Power

140hp

Power Measured @

2100rpm

Max Torque

437lb ft

Displacement

504cu in

Torque Measured @

1525rpm

Operational

Fuel Capacity

65gal

Cooling System Fluid Capacity

14.1gal

Engine Oil Capacity

3.8gal

Hydraulic Fluid Capacity

17.6gal

Final Drives Fluid Capacity

6.3gal

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

5.4mph

Max Speed - Reverse

6.5mph

Undercarriage

Standard Shoe Size

24.1in

Number of Shoes per Side

36

Number of Track Rollers per Side

6

Number of Carrier Rollers per Side

1

Track Gauge

6.2ft in

Dimensions

Length w/o Blade

12.4ft in

Length w/ Blade

16ft in

Height to Top of Cab

10.4ft in

Ground Clearance

1.3ft in
