Buhler Versatile 535 4WD Tractor

Buhler Versatile 535 4WD Tractor Specs front
Buhler Versatile 535 4WD Tractor Specs front
Buhler Versatile 535 4WD Tractor Specs side
Buhler Versatile 535 4WD Tractor Specs side
Buhler Versatile 535 4WD Tractor Specs back
Buhler Versatile 535 4WD Tractor Specs back
Units

Dimensions

Dimensions

A

Overall Length

25.04 in

C

Height to Top of Cab

11.32 ft in

D

Wheelbase

12.9 in

E

Ground Clearance

21.89 in


Specifications

Engine

Engine Make

2347

Engine Model

QSX15

Gross Power

580 hp

Net Power

535 hp

Power Measured @

1800 rpm

Torque Rise

35 %

Displacement

915.4 cu in

Aspiration

turbocharged & air to air aftercooled

Operational

Operating Weight

53500 lb

Hydraulic System Fluid Capacity

30.1 gal

Fuel Capacity

350.1 gal

Engine Oil Capacity

11.7 gal

Cooling System Fluid Capacity

22 gal

Drawbar Static Vertical Load Rating

9000 lb

Turning Radius

16 ft in

Alternator Supplied Amperage

160 amps

Operating Voltage

12 V

Transmission

Transmission Type

Quadshift mechanical 12x4

Number of Forward Gears

12

Number of Reverse Gears

4

Max Speed

21.8 mph

Hydraulic System

Pump Flow Capacity

55 gal/min

Axles

Final Drive

versatile outboard planetary

Hydraulic System

Relief Valve Pressure

2857.3 psi

Number of Remote Control Valves

4

Dimensions

Wheelbase

12.9 in

Overall Length

25.1 in

Height to Top of Cab

11.4 ft in

Ground Clearance

21.9 in

Tire Size

710/70R42
