Bomag CR662RM Asphalt Paver

Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Units

Specifications

Screed

Screed plate thickness

0.5in

Positive crown

3in

Negative crown

1in

Vibrations per minute (max)

3000

Stretch® 16 (electric heat) generator

45.6hp

Stretch® 16 (four oil heaters) 274,000 BTU (total)

2.0 gph

Fastach® 8 (electric heat) generator

45.6hp

Fastach® 8 (two oil heaters) 178,000 BTU

1.3 gph

Engine

Emission Tier Level

Tier 4f

Engine Make

Cummins

Engine Model

QSB6.7

Gross Power

260hp

Power Measured @

2200rpm

Aspiration

Turbocharged

Operational

Fuel Capacity

72gal

Hydraulic System Fluid Capacity

75gal

Cooling System Fluid Capacity

6.5gal

Operating Voltage

12V

Hopper/Paver

Hopper Capacity

30000.1lb

Hopper Length

90in

Trough liner thickness

0.4in

Auger Construction

Cast , High alloy

Remix augers - diameter

12.1in

Auger Thickness

0.7in

Hopper Volume

9.9yd3

Paving Depth - max

12.1in

Hopper Width

118.7in

Paving Width - std

10.4ft in

Feed Tunnel Width

30in

Paving Width - max

30ft in

Paving Speed - max

225ft/min

Travel Speed - max

9.6mph

Auger Diameter

16in

Weights

Tractor Weight

36200lb

Tractor Weight - with Fastach® 8 and hydroflated tires

40200lb

Tractor Weight - with Stretch 16 and hydroflated tires

44100lb

Brakes

Parking brake

Multiple disc
