Bomag BW9ASW Static Smooth Drum Roller

Bomag BW9ASW Static Smooth Drum Roller Specs front
Bomag BW9ASW Static Smooth Drum Roller Specs front
Bomag BW9ASW Static Smooth Drum Roller Specs side
Bomag BW9ASW Static Smooth Drum Roller Specs side
Bomag BW9ASW Static Smooth Drum Roller Specs back
Bomag BW9ASW Static Smooth Drum Roller Specs back
Units

Dimensions

Dimensions

A

Overall Length

15.25 in

B

Overall Width

5.22 ft in

D

Wheelbase

11.01 ft in

E

Ground Clearance

1.38 ft in

F

Drum Diameter - Front

3.34 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2347

Engine Model

4B3.3TAA

Gross Power

84 hp

Power Measured @

2400 rpm

Operational

Fuel Capacity

33.9 gal

Hydraulic System Fluid Capacity

15.1 gal

Cooling System Fluid Capacity

4 gal

Spray Water Capacity

170.4 gal

Max Speed

10.2 mph

Operating Voltage

12 V

Weights

Operating Weight - standard

14080 lb

Operating Weight - max ballast

19320 lb

Max Static Linear Load - Drive Drum

193 lb/in

Max Static Linear Load - guide drum

153 lb/in

Dimensions

Wheelbase

11.1 ft in

Overall Length

15.3 in

Overall Width

5.3 ft in

Height with ROPS

9 ft in

Height with out ROPS

6.2 ft in

Ground Clearance

1.4 ft in

Drum Diameter - Front

3.4 ft in

Drum Diameter - Rear

4.5 ft in
