Bomag BW124PDH-3 Vibratory Compactor
Units
Dimensions
Dimensions
A
Overall Length W/O Blade
11ft in
B
Width Over Tires
3.94ft in
C
Height To Top Of Cab
7.88ft in
D
Wheelbase
5.93in
E
Ground Clearance
12.6in
Overall Length W/ Blade
12.8ft in
Drum
F
Drum Diameter
35.04in
Pad Surface Area
12.6in2
Vibration Frequency 1
41Hz
Vibratory Frequency 2
41Hz
Number Of Pads
70
Centrifugal Force - Low
9666.79lb
Drum Width
47.25in
Nominal Amplitude - High
0.07in
Nominal Amplitude - Low
0.04in
Centrifugal Force - High
19108.77lb
Pad Height
2.17in
Specifications
Engine
Number Of Cylinders
3
Engine Make
2349
Engine Model
F3L2011
Gross Power
49.7hp
Net Power
47hp
Power Measured @
2800rpm
Operational
Operating Weight
7385.5lb
Fuel Capacity
15.9gal
Max Speed
5.6mph
Tires
9.5-24
Operating Voltage
12V
