Bobcat S185 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

10.86ft in

B

Width Over Tires

5.5ft in

C

Height to Top of Cab

6.36ft in

D

Wheelbase

3.38ft in

E

Ground Clearance

7.49in

F

Length w/o Bucket

8.5ft in

G

Clearance at Max Lift and Dump

7.58ft in

H

Reach at Max Lift and Dump

29.65in


Specifications

Engine

Number of Cylinders

4

Engine Make

2334

Engine Model

V2003-M-DI-T

Gross Power

56hp

Power Measured @

2800rpm

Displacement

122.1cu in

Operational

Operational Weight

6220lb

Fuel Capacity

24.1gal

Operating Speed

7.3mph

Max Speed

11.1mph

Loader

Operating Load Rating

1850lb

Tipping Angle

4076degrees

Bucket Capacity

0.5yd3

Hydraulic

Pump Flow Capacity

16.9gal/min

Relief Valve Pressure

3300psi

Dimensions

Length with Bucket

10.9ft in

Length w/o Bucket

8.5ft in

Width Over Tires

5.5ft in

Height to Top of Cab

6.4ft in

Clearance at Max Lift and Dump

7.6ft in

Wheelbase

3.4ft in

Ground Clearance

7.5in

Reach at Max Lift and Dump

29.7in

Turning Radius from Center - machine rear

78.8in
