Bobcat A770 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

11.8ft in

B

Width Over Tires

6.23ft in

C

Height to Top of Cab

6.78ft in

D

Wheelbase

4.03ft in

F

Length w/o Bucket

9.53ft in

H

Reach at Max Lift and Dump

31.5in


Specifications

Engine

Emission Tier Level

Tier 4

Gross Power

92hp

Cooling system

Liquid

Aspiration

Turbocharged

Fuel Type

Turbo Diesel

Operational

Lift Arm Path

Vertical

Operational Weight

9623lb

Fuel Capacity

23.9gal

Max Speed

7.4mph

Loader

Loader Series

M2-Series

Height to hinge pin

10ft in

Operating Load Rating

700lb

Tipping Angle

6650degrees

Bucket Width

68in

Hydraulic

Main pump flow standard

23gal/min

Main pump flow optional

36.6gal/min

Relief Valve Pressure

3500psi

Dimensions

Length with Bucket

11.8ft in

Length w/o Bucket

9.6ft in

Width Over Tires

6.3ft in

Height to Top of Cab

6.8ft in

Wheelbase

4.1ft in

Reach at Max Lift and Dump

31.5in

Turning Radius from Center - machine rear

151.5in

Turning Radius from Center - inc bucket

85.8in

`
