Bitelli BB621C Asphalt Paver

Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
Asphalt Paver
MODEL.UNITS

Dimensions

Dimensions

A

Length W/ Screed

13.26ft in

B

Transport Width

4.6ft in

C

Transport Height

8.54ft in

Transport Width - Hoppers Raised - With End Gates With Extend-A-Mat B Screed

4.59ft in

Length - With Push Roller And Extend-A-Mat B Screed

13.25ft in

Width W/ Hopper Open

9.19ft in

Overall Height

8.53ft in

Track Contact Length

4.7ft in


Specifications

Engine

Engine Make

2360

Engine Model

2M 41L

Gross Power

35.4hp

Engine Model

Hatz 2M 41L

Operational

Operating Weight W/O Screed

7275.3lb

Operating Weight W/ Screed

8818.5lb

Fuel Capacity

18.3gal

Hydraulic System Fluid Capacity

19.3gal

Hopper/Paver

Hopper Capacity

4lb

Paving Width - Std

4.6ft in

Paving Width - Max

9.9ft in

Paving Speed - Max

108.3ft/min

Travel Speed - Max

2.6mph

Weights

Tractor Weight

7275.3lb

Operating Weight - With Extend-A-Mat 8-16b Screed

8818.5lb

Operating Weight - With Screed

8818.5lb

Operating Specifications

Paving Width Minimum

1.7ft in

Paving Width Maximum

9.9ft in

Service Refill Capacities

Cooling System

5.9gal

Fuel Tank Capacity

18.3gal

Hydraulic Oil Tank

19.3gal

Drive System

Maximum Paving Speed

108.27 ft/min

Maximum Travel Speed

2.6mph

Hopper

Hopper Capacity

105.94 ft
