Bell B20D 6x6 Articulated Dump Truck

Bell B20D 6x6 Articulated Dump Truck Specs front
Bell B20D 6x6 Articulated Dump Truck Specs front
Bell B20D 6x6 Articulated Dump Truck Specs side
Bell B20D 6x6 Articulated Dump Truck Specs side
Bell B20D 6x6 Articulated Dump Truck Specs back
Bell B20D 6x6 Articulated Dump Truck Specs back
Units

Dimensions

Dimensions

A

Overall Length

29.5 ft in

B

Overall Width

8.4 ft in

C

Overall Height

11.13 ft in

Dump

H

Dump Angle

70 degrees


Specifications

Engine

Engine Make

2345

Engine Model

OM906LA

Gross Power

205 hp

Max Torque

597.5 lb ft

Operational

Fuel Capacity

52.9 gal

Tire Size

20.5r25

Transmission

Transmission Type

ZF HP592

Number of Forward Gears

6

Number of Reverse Gears

1

Max Speed

37.3 mph

Weights

Total Empty

32628.5 lb

Total Loaded

39683.3 lb

Dump

Capacity - Struck

11.2 yd3

Capacity - Heaped

14.4 yd3

Dump Angle

70 degrees

Raise Time

12 sec

Lower Time

6 sec

Dimensions

Overall Length

29.5 ft in

Overall Width

8.4 ft in

Overall Height

11.2 ft in
