Ammann ASC250PD Vibratory Compactor
Units
Dimensions
Dimensions
A
Overall Length W/O Blade
21.53ft in
B
Width Over Tires
8.21ft in
C
Height To Top Of Cab
10.72ft in
D
Wheelbase
10.8in
E
Ground Clearance
19.69in
Drum
F
Drum Diameter
63in
Pad Height
6.07in
Pad Surface Area
22.48in2
Vibration Frequency 1
28Hz
Vibratory Frequency 2
34Hz
Number Of Pads
150
Centrifugal Force - Low
103412.11lb
Drum Width
88.19in
Nominal Amplitude - High
0.05in
Nominal Amplitude - Low
0.09in
Centrifugal Force - High
76435.04lb
Specifications
Engine
Engine Make
2347
Engine Model
QSB6.7-C220
Net Power
208hp
Operational
Operating Weight
56251lb
Fuel Capacity
107gal
Max Speed
6.3mph
Tires
23.5-25
