Ammann ASC150HDPD Vibratory Compactor
Units
Dimensions
Dimensions
A
Overall Length W/O Blade
18.66ft in
B
Width Over Tires
8.21ft in
C
Height To Top Of Cab
9.95ft in
D
Wheelbase
9.26in
E
Ground Clearance
16.54in
Drum
F
Drum Diameter
56.7in
Pad Height
3.94in
Pad Surface Area
18.61in2
Vibration Frequency 1
29Hz
Vibratory Frequency 2
35Hz
Number Of Pads
140
Centrifugal Force - Low
73062.91lb
Drum Width
86.62in
Nominal Amplitude - High
0.04in
Nominal Amplitude - Low
0.08in
Centrifugal Force - High
53279.72lb
Specifications
Engine
Engine Make
2347
Engine Model
QSB4.5-C160
Net Power
158hp
Operational
Operating Weight
34226.8lb
Fuel Capacity
108.4gal
Max Speed
6.3mph
Tires
23.1-26
