Airman AX22U-4 Mini Excavator

Airman AX22U-4 Mini Excavator Specs front
Airman AX22U-4 Mini Excavator Specs front
Airman AX22U-4 Mini Excavator Specs side
Airman AX22U-4 Mini Excavator Specs side
Airman AX22U-4 Mini Excavator Specs extended
Airman AX22U-4 Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

12.9 ft in

C

Shipping Height of Unit

7.91 ft in

J

Max Loading Height

9.42 ft in

K

Max Reach Along Ground

13.65 ft in

L

Max Vertical Wall Digging Depth

6.34 ft in

M

Max Digging Depth

7.62 ft in

Dimensions

B

Width to Outside of Tracks

4.76 ft in

D

Length of Track on Ground

6.24 ft in

E

Ground Clearance

0.97 ft in

H

Tail Swing Radius

2.7 ft in

Undercarriage

N

Shoe Size

9.85 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2348

Engine Model

3TNV76

Gross Power

19.6 hp

Power Measured @

2400 rpm

Displacement

67.8 cu in

Operational

Operating Weight

5269.1 lb

Hydraulic System Relief Valve Pressure

3045.8 psi

Hydraulic Pump Flow Capacity

12.5 gal/min

Undercarriage

Shoe Size

9.9 in

Max Travel Speed

1.7 mph

Buckets

Reference Bucket Capacity

0.1 yd3

Boom/Stick Option (HEX) 1

Shipping Height of Unit

8 ft in

Shipping Length of Unit

12.9 ft in

Max Digging Depth

7.7 ft in

Max Reach Along Ground

13.7 ft in

Max Loading Height

9.5 ft in

Max Vertical Wall Digging Depth

6.4 ft in

Dimensions

Width to Outside of Tracks

4.8 ft in

Ground Clearance

1 ft in

Tail Swing Radius

2.7 ft in

Length of Track on Ground

6.3 ft in
