Agrale 4230 Utility Tractor

Agrale 4230 Utility Tractor Specs front
Agrale 4230 Utility Tractor Specs front
Agrale 4230 Utility Tractor Specs side
Agrale 4230 Utility Tractor Specs side
Agrale 4230 Utility Tractor Specs back
Agrale 4230 Utility Tractor Specs back
Units

Specifications

Engine

Number of Cylinders

2

Engine Make

2444

Engine Model

M 790

Gross Power

30 hp

PTO Power

22.2 hp

Power Measured @

3000 rpm

Max Torque

51.7 lb ft

Torque Measured @

2550 rpm

Displacement

77.6

Operational

Fuel Capacity

10.4 gal

Engine Oil Capacity

1.6 gal

Hydraulic System Fluid Capacity

4.3 gal

3 Point Hitch Lift Capacity @ 24 inches

1433.1 lb

Tire Size Front - 2wd / 4wd

5.00x15

Rear Tires Size 2wd/4wd

9.50x24R1

Operating Voltage

14 V

Alternator Supplied Amperage

55 amps

Transmission

Number of Forward Gears

6

Number of Reverse Gears

2

Max Speed

13.8 mph

Hydraulic System

Relief Valve Setting

2610.7

Pump Flow Capacity

7.6 gal/min

Number of Remote Control Valves

6
