Komatsu GD300A-1 Motor Grader

Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Units

Dimensions

Dimensions

A

Overall Length

21.99ft in

B

Width Over Tires

6.71ft in

D

Wheelbase

16.11ft in

E

Rear Ground Clearance

1.12ft in

G

Tandem Axle Wheelbase

3.93ft in

F

Front Ground Clearance

1.4ft in

H

Blade Base

7.11ft in

Height To Top Of Isomount Cab

10.27ft in


Specifications

Engine

Engine Make

2238

Engine Model

4D105-5

Net Power Gear 5-6

75hp

Max Power

75hp

Net Torque Gears 5-6

194lb ft

Displacement

264cu in

Operational

Std Operation Weight - Front Axle

4960.5lb

Std Operation Weight - Rear Axle

11574.3lb

Std Operation Weight - Total

16534.7lb

Tire Size

front 9.00-20-10PR, rear 10.00-20-10PR

Steering

Articulation Angle

30degrees

Turning Radius

18.1ft in

Transmission

Transmission Type

constant mesh and synchromesh combined

Number Of Gears - Forward

5

Number Of Gears - Reverse

4

Max Speed - Forward

18.9mph

Max Speed - Reverse

19.3mph

Front Axle

Wheel Lean

19degrees

Oscillation - Total

26degrees

Ground Clearance

1.4ft in

Moldboard

Moldboard Width

10.2ft in

Moldboard Height

22.9in

Moldboard Thickness

0.7in

Max Depth Of Cut

10.7in

Circle

Max Reach Outside Tires - Left

45.3in

Max Reach Outside Tires - Right

43.4in

Max Lift Above Ground

13in
